Functions & Features
Features
Connect Your Devices
Automatically detects the appropriate connection mode to use
Broadband Router Mode: Connect an Ethernet cable to share your wired connection
Mobile Router Mode: Connect a 3G USB adapter to share your mobile connection1
Hotspot Mode: Share Internet access from a Wi-Fi hotspot with all of your devices
Shares your Internet connection through Wireless AC with combined wireless speeds of up to 600 Mbps2
Saves your connection settings for automatic connection later
Share Your Files
Plug in a USB drive for easy file access
Stream your files over the Internet to your mobile device with the mydlink™ SharePort™ app
Stream media to UPnP-capable devices
Charge Your Devices
Charge your mobile devices including iPads and tablets via the USB port
Technical Specifications
General
Device Interfaces
802.11 a/b/g/n/ac Wireless LAN, up to 600 Mbps2
WPS button
Power switch
Reset button
WAN 10/100 Ethernet port
USB 2.0 Type A port (1 A) for compatible 3G adapters, USB drive, or charging other devices
LEDs
Power/Status
Standards
IEEE 802.11ac
IEEE 802.11n
IEEE 802.11g
IEEE 802.11b
IEEE 802.11a
IEEE 802.3
IEEE 802.3x
IEEE 802.3u
USB 2.0
Internet Modes
Broadband Router Mode
Mobile Router Mode
Wi-Fi Hotspot Mode
Power Modes
Router/Charger4
Antennas
Internal antennas
Functionality
Sharing Features
mydlink™ SharePort™ app
Remote Access Mode: Access files through the Internet3
Local Access Mode: Access files from any device connected to the DIR-518L
App supports iPhone, iPad, iPod Touch, and Android devices
SharePort™ Web Access support (Web browser)
Access files from any device connected to the DIR-518L
Security
Wi-Fi Protected Access (WPA/WPA2)
WEP 64/128-bit encryption
WPS 2.0 (PBC)
Advanced Features
Guest Zone support
IPv6
Wi-Fi WMM Quality of Service (QoS)
UPnP support
Advanced Firewall Features
Network Address Translation (NAT)
MAC address filtering
Device Management
User-friendly web UI with desktop and mobile interfaces
Physical
Dimensions (L x W x H)
61.0 x 71.0 x 40.0 mm (2.4 x 2.79 x 1.57 inches)
Weight
130 g (4.58 ounces)
Power
Input: 100 to 240 V AC, 50-60 Hz
USB Type A Port Output: 5 V DC
500 mA (Router mode)
1000 mA (Charger mode)
Temperature
Operating: 0 to 40 °C (32 to 104 °F)
Storage: -10 to 45 °C (14 to 113 °F)
Humidity
Operating: 10% to 75% non-condensing
Storage: 5% to 75% non-condensing
Certifications
FCC
CE
IC
C-Tick
cUL
